WIRE ROPE
We are India's oldest USHA MARTIN LTD associate and distributor. Offering you the best Wire Ropes in the world.
​
E. E. Karachiwala & Co. have specialised in supplying multi stranded ungalvanised and galvanised steel wire rope since 1911. We stock from 0.5mm up to 103mm in various constructions including 1X19, 7X7,6X19, 7X19, 6X36, 8X19, 8X26, 18x7, 19X7 and 35X7 with both Fibre Core and Steel Cores. In addition to these conventional steel wire ropes we can offer special wire ropes from high quality manufacturers.
Most wire ropes operate in demanding conditions and must resist crushing, bending fatigue and abrasion. We recognise that it is vital that all of our wire ropes need to perform to the highest levels to maximise service life therefore increasing productivity for the end user. With our technical experience we have worked hard with our partners to ensure that all material is manufactured to the very best standards in the steel wire rope industry.
Each steel wire rope can be supplied fully assembled complete with end terminals such as a thimble eyes, swaged ends and wedge sockets as well as many other solutions. These cable assemblies are manufactured in house by our team of engineers complete to your specifications.
All material is certified and has full traceability in line with our ISO9001 procedures.
​
Click Below to learn more...
Please click on each item for catalogs
6x19 construction wire rope is available with either FC (fibre core) or WSC (wire strand core). When supplied with a wsc the rope is more commonly referred to as 7x19. The rope is very popular in diameters from 3mm to 16mm and is used on a variety of applications. 6x19 FC and 6x19 WSC (7x19) is very flexible in diameters 3mm to 6mm and is used for many requirements where wire ropes are running over pulleys.
• Industrial door cables
• Garage door cables
• Where cables are required to run over pulleys
• Control cables
• General engineering applications
• Gym equipment cables
• Wind turbine
• Wire rope slings
• Whip checks
• Winch ropes
6x36 is a flexible general engineering wire rope readily available in galvanised and ungalvanised coatings. The wire rope has an equal lay construction (warrington seale) and achieves a superior breaking load to the 6x19 construction range. The construction has been designed to give a flexible rope with a good fatigue life. A 6x36 wire rope is available with either FC (fibre core) or IWRC (independent wire rope core) and is used for a wide range of applications, examples of which are shown below:
• Wire rope slings
• General engineering applications
• Crane ropes
• Hoist rope
• Winch ropes
• Holding and closing ropes for grab cranes
• Tow ropes
• Luffing ropes
• Pursing wires
• Mooring ropes
• Lifeboat falls
• Wire rope rigging applications
Superior Elevator & Lift Application Wire Ropes, with multiple Tensile designations & Core types. Used by OEM's and by Maintenance and Repair customers.
19X7 is available in both galvanised and ungalvanised finish. The construction family includes 18X7 and 19X7. For further flexibility and other performance characteristics we also supply 32X7, 34X7, 35X7 and 37X7.
Example of applications for non-rotating wire ropes include the following
-
Crane rope
-
Main hoist rope
-
Whip hoist rope
-
Pillar crane rope
-
Deck crane rope
-
Offshore crane rope
35X7 is available in both galvanised and ungalvanised finish with either ordinary or langs lay. The construction family includes 34X7 and 37X7.
Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications as well as being available with plastic impregnated or in compacted constructions.
Example of applications for non-rotating wire ropes include the following
-
Crane rope
-
Main hoist rope
-
Whip hoist rope
-
Pillar crane rope
-
Deck crane rope
-
Offshore crane rope
​Applications:
-
Wire rope slings
-
General engineering applications
-
Crane ropes
-
Hoist rope
-
Winch ropes
-
Holding and closing ropes for grab cranes
-
Tow ropes
-
Luffing ropes
-
Pursing wires
-
Mooring ropes
-
Lifeboat falls
-
Wire rope rigging applications
Applications:
-
Crane rope
-
Main hoist rope
-
Whip hoist rope
-
Pillar crane rope
-
Deck crane rope
-
Offshore crane rope
Applications:
-
Crane rope
-
Main hoist rope
-
Whip hoist rope
-
Pillar crane rope
-
Deck crane rope
-
Offshore crane rope
WHY USHA MARTIN ROPE?
GUARANTEED RAW MATERIAL QUALITY
-
Developed, manufactured and quality certified by own Steel Plant.
-
Tailor made raw materials to ensure consistent rope quality and desired end-properties.
GUARANTEED PRODUCT QUALITY
-
State-of-the-art pickling plant.
-
State-of-the-art patenting furnaces.
-
Latest generation wire-drawing machinery
-
Computerised rope design.
-
In-house developed rope making machinery for manufacturing high-performance ropes.
-
Breaking load and fatigue test equipment to guarantee desired performance and quality.
GUARANTEED QUALITY SYSTEMS
-
ISO 9001:2000
-
API
-
OTIS
-
ABS
-
LLOYDS
-
NKK
-
JIPM
QUALITY POLICY
“Our quality policy is to fulfil customers’ requirement through reliable products and services meeting all regulatory requirements and through continual improvement of our quality management system.
ROBUST PROCESS CONTROL
-
Qualified supervisors & operators trained in own institution on product process and equipment.
-
Regular training of operations staff at HRD center.
-
Visual display of process parameters at each stage of processing.
-
Stringent quality control at every stage of manufacturing.
TPM policy
“It is our policy to induce change in all employees by delegation, empowerment and motivation to achieve total participation towards zero accident, zero defect and zero failure.”
​
​
HOW TO ORDER A ROPE
-
Nominal Diameter and tolerance.
-
Construction/Class/Brand Name.
-
Finish (galvanized or ungalvanised)
-
Tensile Strength
-
Minimum Breaking load requiement.
-
Core-Fibre/IWRC/WSC.
-
Lay-eg. Right hand regular lay.
-
Lubrication
-
Packing wooden reel/steel reel/coils.
-
Particulars of fittings
-
Performed / Non-preformed
-
Exact length per reel / coil etc (special length tolerance, if any)
-
Delivery time
-
Special requirements
-
Pre-stretching
-
Packaging
-
Identification
-
Third-party inspection
-
​
SAFETY INFORMATION
-
Wire rope will fail if worn out, shock loaded, overloaded, misused, damaged, improperly maintained or abused.
-
Always inspect wire rope for wear, damage or abuse before use.
-
Never use a wire rope which is worn out, damaged, corroded or abused.
-
Never overload or shock load a wire rope.
-
Use the correct design factor for the application.
-
Inform yourself : Read and understand the machinery manufactures handbook and guidance from the wire rope manufacturer.
-
Refer to applicable directives, regulations, standards and codes concerning inspection, examination and rope removal criteria.
